General Specs |
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Door Color | Stainless Steel |
| Handle Color | Stainless Steel |
| Trim Color | Stainless Steel |
| Total Capacity (cu. ft.) | 5.6 |
| Number of Oven(s) | Single |
| Fuel Type | Natural Gas |
| Door Panel Type | Glass |
| Burner Type | Sealed |
| Range Type | Freestanding |
| Number of Elements/Burners | 5 |
| Cooktop Surface Style | Burner Grate |
| Grate Material | Cast Iron |
| Oven Cleaning Method | Manual Clean |
| Total Number Of Oven Racks | 2 |
| Total Number Of Rack Positions | 5 |
| Oven Features | Broiler in Oven, Keep Warm, Oven Light, Proofing Mode, Delay Bake/Start |
| Cooktop Features | Continuous Grate, LP Convertible, Dishwasher Safe Grates, Warming Zone, Removable Grates |
| Air Fry | No |
| Induction Cooking | No |
| Convection Cooking | Yes |
| Smart Compatible | No |
| Outdoor Approved | No |
| Downdraft Ventilation | No |
| Drawer Type | No Drawer |
| Appliance Fit Width (in.) | 36 |
| Width (in.) | 35.9375 |
| Height (in.) | 36 |
| Depth (in.) | 24.7656 |
| Depth w/Door Open 90 Degrees (in.) | 45.4687 |
| Cut Out Depth (in.) | 25 |
| Cut Out Width (in.) | 36 |
| Cut Out Height (in.) | 36 |
| Shipping Width (in.) | 38.75 |
| Shipping Depth (in.) | 28 |
| Shipping Height (in.) | 34.0625 |
| Product Weight (lbs.) | 207 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Commercial Use Approved | No |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Collection | 500 Series |
| Series | 500 Series |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 15 |
Additional Dimensions |
| Overall oven interior dimensions (HxWxD) | 15.04" x 28.46" x 17.72" |
| Usable oven interior dimensions (HxWxD) | 14.57" x 26.97" x 16.14" |
| Adjustable range height | 35.5625" Min. - 36.625" Max. |
| Plug type | US 3-prong |
| Cord length | 60" with plug |
| Gas type | Natural gas 14.9 mbar (USA) [7" WC] |
| Alternative gas type | LP 27.4 mbar (USA)[11" WC] |
| Bake / broil burner power BTU | 17,000 / 14,000 BTU |
| Total cooktop (NG / LP) BTU | 54,000 / 52,000 |
| Power of front left burner (NG / LP) BTU | 5,000 / 5,000 |
| Power of back left burner (NG / LP) BTU | 12,000 / 12,000 |
| Power of center burner (NG / LP) BTU | 20,000 / 18,000 |
| Power of back right burner (NG / LP) BTU | 5,000 / 5,000 |
| Power of front right burner (NG / LP) BTU | 12,000 / 12,000 |
